Metals and non-metals


  • How can we tell if something is made of a metal or a non-metal?
  • How do we decide what material to use when we want to make or build something?

Introducing the topic

The first important message of this unit is that purpose comes before choice of material. Once we know the purpose of whatever product it is we want to produce, we can decide what properties we need the building material to have, and then choose a material that possesses those properties.

In the first unit of Matter and Materials, we distinguish between materials that are metallic and those that are not. Although this is not a formal definition, we group everything that is not metallic into the category of non-metals. We make the distinction between metals and non-metals on the basis of properties, and so it is important to establish a firm understanding of the term properties early on.

You could start with a conversation about building something new (like the dog house example below), then steer the conversation towards properties by asking questions around the ways in which the object will be used.

In this chapter we will learn about metals and non-metals. Do you remember learning about materials in Grade 4. Metals and non-metals are two different classes of materials. Each class has its own unique properties. Properties are the things that are special or unique about an object or a material. We can use the properties of a material to describe what it is like. For example, we could say that a property of a gas is that it can be compressed.

When we want to make a new product (a building or a tool or any kind of object) we first have to decide what the purpose of that product will be. Perhaps we want to make a tool for digging in the garden, or a kennel (dog house) for our new puppy. The purpose of the product will help us decide which would be the best material with which to make the object.

What would be the best material for a digging tool? Surely we would need a tool that is strong and durable; with a sharp edge that will allow us to cut through the soil when we dig into it.


What material would allow us to make a dog house that is cool in summer and warm in winter?


Wood

What material would you choose to make a spade for digging in the garden?


Metal or hard plastic


The next activity is about the things we think about when we choose materials for a specific purpose. In this case the purpose is building a house.

Choosing a material to build a house


The purpose of the activity is for learners to discover that there are many options to choose from when choosing materials for a particular job, and that circumstances may dictate which material would be the best choice. For instance, the learners are required to say which material (corrugated iron or wood) would be best suited for a house located next to the ocean. They should be encouraged to think about aspects such as corrosion (which will be dealt with in greater detail later) and thermal conductivity (also covered later) which would make wood the better choice. Availability and cost are also aspects that could be brought into the conversation. How available is corrugated iron vs wood?

INSTRUCTIONS:

  1. When we choose a material for a certain purpose, we look for a material with the right properties for the job. Look at the two pictures of houses below.
  2. Can you see that house A and house B are made of different materials?
  3. Answer the questions that follow.

QUESTIONS:

What material was used to build house A?


House A is made of corrugated iron (tin/metal).

What material was used to build house B?


House B is made of wood.

If you had to build a house next to the ocean, which one would you choose, house A or house B?



House B

Teacher note: House B would be a better choice, but house A is not wrong. Read the suggested answer to the next question to see why B is the better choice.

Write down a reason why you would build this house next to the ocean rather than the other one.




Metal objects usually rust in the wet, salty air close to the ocean. That would make a corrugated iron house a poor choice. Metals are also good conductors of heat, which would make the iron house cold inside when the outside temperature is cold, and hot inside when the weather is hot.

Teacher note: House B (the wooden house) would be the best choice, provided that wood is cheaply available. Often people build tin houses because it is the cheapest material available.

Write down at least three other materials that could be used for building a house.



Bricks, reeds, concrete, hard plastic sheets (any durable, waterproof material would be suitable.)


Now that we have looked at the different types of materials that you could use to build a house and seen that there are different cases when you would use one material or another, let's look at the actual properties of metals and non-metals.

Properties of metals


In this section learners will investigate and contrast the properties of metals and materials that are not metallic (so-called 'non-metals'). You could draw their attention to metallic and non-metallic items in the classroom, or in pictures, as an introduction to the topic and related activities.

Explanation of the new words to be covered in this section, associated with metals.

  • Properties: The words we use to describe a certain type of matter, a material or even an object, e.g. a property of gases is that they can be compressed.
  • Metal: A shiny solid that can conduct heat or electricity and can be formed into sheets or wire.
  • Lustre/lustrous: The 'shine' we see when light reflects off the surface of a metallic object such as a key or a coin. We say that metals are 'lustrous'.
  • Dense: Dense materials have lots of particles packed close together. Less dense materials have fewer particles packed together. When we compare a metal teaspoon with a plastic teaspoon of the same size and shape, the metal teaspoon would be heavier, because metal is more dense than plastic. NB: Do not refer to dense objects as 'heavy' and less dense objects as 'light'. This creates a misconception that density is the same as mass. Density is the mass per unit volume. Mass does therefore influence density, but it is not the same as density. Rather explain it as how closely the particles in a substance is packed, which includes both mass and volume. The more particles that can fit into a specific size/shape, the more dense the object will be.
  • Malleable: Malleable materials can be hammered into different shapes without breaking. As a simple example you could think of bending a paper clip into a new shape.
So how can we tell if something is made of metal?

Good question Tom! Let's look at the properties of metals. A property is a word used to describe a material or object and tells us something about it.

  • Metals are usually shiny. The shine that we see when light reflects off the surface of a metal is called the lustre of the metal.
  • Most metals are hard and they feel heavy.
  • We say metals are dense as their particles are packed close together.
  • Metals conduct electricity and heat well. (You will learn more about electricity next term. In Grade 6, you will learn about metals as conductors of electricity.)
  • Metals are malleable (they can be shaped into flat sheets) and they are ductile (this means they can be made into thin wire)
  • Most metals can be heated to high temperatures without melting or changing their shape, which is one of the reasons why pots and pans are made of metal. Can you think of any other reasons why pots and pans are made of metal?
  • Metals are mined from the Earth. You will learn more about this in another subject, Social Sciences.

Here, the conversation could be directed in such a way that learners realise that when we cook food, we heat the outside of the pot, the food cooks on the inside. That means the heat that cooks the food travels through the metal. Would heat travel through plastic in the same way? No, the plastic would melt. Would heat travel through wood in the same way? No, the wood would burn.

Aaah! All these new words about metals! I still do not really know what they all mean!

Do not worry Tom! These are new, big words, but here is an activity in which we can investigate some of the properties of metals. We will use our skills of observation (looking, listening and touching) during the investigation.

Here, a comment about skills of observation may be appropriate. What are skills of observation? What does it mean to observe something? Does observation only refer to things we can see? No, we can also observe (hear) sounds, observe (smell) odours, observe (feel) textures and observe (taste) flavours. Learners might also find it difficult to express what they observe. Encourage them to find words to write down, or say what they see, hear, smell, feel and taste. This will help to develop their science vocabulary.

What are the properties of metals?


This activity is ideal for small group work. Learners could discuss their observations in the group and fill in the table of observations together. Learners may need help finding words for what they are observing. For this reason a word box is provided, but learners could also be encouraged to use their own words. Since this is an investigation, there are no right or wrong answer, as long as learners can justify their answers from their own observations. Rather learners should be encouraged to discover freely, and then link descriptive words to their observations. At the end of both investigations (Theproperties of metals and The properties of non-metals) they should be able to compile a list of the general properties of metals and non-metals similar to the lists given at the end of this unit.

Tom identified a problem and a question - he wants to experience the properties of metals. In a science investigation we want to answer a question or find something out.

What would you like to find out in this investigation? (We call this the aim of the investigation.)



MATERIALS:

  • coins
  • metal spoon
  • metal pencil sharpener
  • metal nail or screw
  • paper clip or thumb tack
  • pin
  • steel wool
  • metal bottle top

METHOD:

  1. Afew metal objects have been placed in front of you. Notice all the different shapes. Write the name of each object in the table below.
  2. Hold each object in your hand. Does it feel hot or cold? Rough or smooth?
  3. Look at each object carefully. Is it shiny or dull? Can you describe its colour?
  4. Drop each object on the floor, or tap it. What sound does it make?
  5. Write your observations in the table below (you may use words from the box below or you may use your own words).

shiny, dull, rough, hard, smooth, makes a ringing sound, cold, warm, heavy, rigid, sharp, flexible, soft, light

OBSERVATIONS:

Name of the object

How the object feels when I touch it

What the object looks like

The sound that is made when the object is tapped or dropped

CONCLUSION:

What have you learned from investigating the properties of metals?





Remember when we looked at the two different houses made from tin and wood? Metals are used to make objects because of the properties that they have.

The properties of metals make them useful to make things


INSTRUCTIONS:

  1. Now that you have investigated the properties of metals, look at the following photos of different objects made from metal.
  2. Answer the questions about each object.
A metal pot. http://www.flickr.com/photos/txberiu/2608488360/

Describe the properties of the metal that this pot is made from.


The pot is shiny, strong and hard, it conducts heat, and only melts at very high temperatures

Why are some of the properties useful to the function of the pot.





Being strong and hard is useful as the pot needs to be able to carry food and you do not want it to break or shatter if you put it down hard on a surface. The metal conducts heat which is useful to cooking food (heat conductivity of metals is only meant to be introduced in the next chapter, but it can be mentioned here.) But the pot also will not melt as metals only melt at very high temperatures, much higher than the highest temperature the stove is able to reach.

A barbed wire fence.

This fence in the next photo is made from metal wire. What property of metal allows us to make this barbed wire fence from metal?



Metal is ductile meaning it can be made into thin wires without breaking, which is why we can make barbed wire.

A spanner made from metal.

What properties does a spanner need to have in order to be used to tighten bolts?


The spanner must be hard and strong.

How do the properties of metal help the functioning of a spanner?



The metal is strong and hard and the spanner needs to be strong and hard. The metal will not break when trying to tighten a bolt.

If the spanner was made from plastic, do you think it would work as well? Why?



A plastic spanner would not work so well as it would easily break. Plastic is not as strong or hard as metal.

Coins are made from different metals.
Why do you think coins are made from metals?

This is because metals are hard and strong. Coins need to be hard and strong as they are often in a wallet where they bump against other coins, they are put into machines, such as to pay for parking, they might be slammed down on a counter when buying something. All these actions make it necessary for coins to be durable, so that they won't break easily. Coins are therefore made from metal.

A tank made from corrugated iron.

This structure is made from sheets of corrugated iron metal. What property of metal allows people to make sheets of metal like this?



Metal is malleable meaning it can be hammered and shaped into thin sheets of metal.



We have said that metals are shiny (they have lustre). But sometimes, when metal gets old it becomes dull. If something is dull, it has lost its shine. There are ways to make metals shiny again.

How can dirty copper coins be cleaned?


The purpose of this activity is for learners to investigate ways to make metals shiny again - do not tell them directly what to do, but rather let them investigate and find out for themselves. They can then write up the activity after completing it. Materials to bring to class are old cloths, Brasso, coins, old pots, a bowl of water. Try and bring some metal objects to school which are old and dull, especially old metal pots which you may have at home. Place the objects in front of the learners and ask them to find the best way to make a metal object shiny again. Let them compare rubbing with a cloth, rubbing with a cloth dipped in water and rubbing with a cloth with some Brasso.

INSTRUCTIONS:

  1. In this activity, you will not be given the list of materials and a method to follow.
  2. Rather, you have to come up with your own steps in this activity to answer the question.
  3. Your teacher will place various objects in front of you or the class.
  4. Experiment with the objects and see how you can best answer the question for this investigation.

QUESTIONS:

What question were you trying to answer in this investigation?



How can you make a metal object shiny again? How can you clean dirty copper coins or pots?

Write the list of materials that you needed for this activity. Write it in a bulleted list.







  • cloths
  • Brasso
  • coins
  • old pots
  • a bowl of water

Imagine you had to tell the Thunderbolt kids how to do this activity to answer your question. Write down the steps to follow in order to complete this activity. Use your experience from experimenting with the objects to come up with a method for the activity. Remember to number the steps in the method.











Assess the learner's ability to record what they did and write short, brief sentences. You might want to start them off with the first step, depending on what you did in class. For example it might be: "Examine an old, dull metal object such as a coin or old pot", the step 2 is "Rub a spot on the surface of the object with a cloth to see if you can make it shiny again", then step 3 "Dip the cloth in water and rub a different spot on the surface of the object, or a different coin", and step 4 "Pour some brasso onto the cloth and rub this onto another spot on the surface of the object. Let the Brasso dry and then polish it off", etc

What can you conclude was the best and quickest way to make dull metal shiny again?



Something about the fact that rubbing with a cloth and brasso is the best way to make a dull metal object shiny again.



Properties of non-metals


Explanation of new words in this section

  • Dull: Dull is the opposite of shiny. When a surface is shiny, it acts like a mirror. An example could be paper or your school shirt. NB: The reflection of light is not done at this level, but dullness can be defined as the scattered reflection of light off a surface. Light is uniformly reflected off a shiny surface, for example off a mirror.
  • Brittle: Brittle materials crack or break easily. Glass is brittle, and so is clay (pottery).
  • Insulator: Insulators are materials which prevent the flow of heat (thermal insulators) or electrical current (electrical insulators). Glass, porcelain, pottery and plastic are examples.
How can we tell if something is made of a non-metal?

Non-metals are materials that do not have the same properties as metals.

  • Non-metals are not shiny, but tend to be dull.
  • Many non-metals are not bendy (flexible) but brittle. This means that they will break when we try to bend them with enough force.
  • Non-metals do not conduct electricity or heat well. We call them insulators. Can you think of a reason why pots and pans often have plastic or wooden handles?

This conversation could be linked to an earlier conversation in which learners were helped to discover that metals are good conductors of heat ("when we cook food, we heat the outside of the pot, but the food cooks on the inside'). That means the heat can also travel along the handle of the pot or pan and burn our hands. Would heat travel through plastic or wood in the same way? No, the plastic or wood acts as insulator, to protect our hands from the heat. These materials do not conduct heat well. Learners could also be reminded that a hot pot or pan could also be handled with a thick cloth or oven mitt to protect the hands. Cloth does not conduct heat well either.

This kettle is made from metal and has a plastic handle.

In the next activity we will investigate some of the properties of non-metals. We will test and observe the non-metals in the same way that we tested the metals in the previous activity. This is so that we can compare metals and non-metals later on.

The properties of non-metals


This activity is ideal for small group work. Learners could discuss their observations in the group and fill in the table of observations together. Learners may need help finding words for what they are observing. For this reason a word box is provided, but learners could also be encouraged to use their own words. Since this is an investigation, there are no right or wrong answers. Rather learners should be encouraged to discover freely, and then link descriptive words to their observations. At the end of both investigations (The properties of metals and The properties ofnon-metals) they should be able to compile a list of the general properties of metals and non-metals similar to the lists given at the end of this unit.

AIM: What do you want to find out by doing this investigation.



I want to find out about the properties of non-metals.

MATERIALS:

  • paper or cardboard
  • cotton wool
  • fabric
  • plastic spoon
  • cork
  • sponge
  • piece of chalk
  • small, strong glass (learners should not drop this on the floor)

METHOD:

  1. Afew non-metal objects have been placed in front of you. Write the name of each object in the table below.
  2. Hold each object in your hand. Does it feel hot or cold? Rough or smooth?
  3. Look at each object carefully. Is it shiny or dull? Can you describe its colour?
  4. Drop each object on the floor, or tap it. What sound does it make?
  5. Write your observations in the table below (you may use words from the box below or you may use your own words).

shiny, dull, rough, hard, smooth, makes a ringing sound, cold, warm, heavy, rigid, sharp, flexible, soft, light

OBSERVATIONS:

Fill in the observations from your investigation of different non-metals below.

Name of the object

How the object feels when I touch it

What the object looks like

The sound that is made when the object is tapped or dropped


Comparing metals and non-metals


What have we learnt about the properties of metals and non-metals? Now we are ready to compare the properties of metals and non-metals. Read through the two lists below. Do you agree with the properties that have been listed? Are there other properties that you would like to add?

Metals are (mostly):

  • solid and strong;
  • malleable and ductile (this means they can be hammered or bent into different shapes);
  • shiny or silvery (lustrous), especially when they are new; and
  • cold to touch.

Non-metals:

  • can be soft or flexible, like rubber;
  • can be hard and brittle, like glass;
  • do not have a silvery (lustrous) appearance, but tend to be dull;
  • can be grouped into different categories (ceramics, wood, rubber, plastic, glass etc.); and
  • usually feels neither cold nor hot.
  • Every type of matter has its own set of properties.
  • "Shiny", "brittle", "malleable", "dense" are all examples of properties of materials. There are many more examples.
  • Metals and non-metals have different properties.
  • Materials are useful because of their properties.
  • Metals are mined from the Earth.


What does the word "property" mean?



Properties are the things that are special about an object or a material. The properties of a material tells us what it is like.

How can we tell if something is made of metal?




Things that are made of metal is shiny, and hard and they can sometimes feel heavy.

What does it mean to 'use our skills of observation'?



Skills of observation are looking, listening and touching. Smelling and tasting are also forms of observation.

Design an investigation in which you are trying to work out whether an object is made of metal or a non-metal. You do not need to write out the materials and apparatus required. Rather, explain in a paragraph about the different types of tests you would do to determine if something is made of a metal or a non-metal.









Learners must use their experience from the investigations to explore the properties of metals and non-metals in this chapter, and from designing their own investigation with the Brasso and dull metals. They should explain some tests to do and the result from the test will say whether it is a metal or not. For example, they could drop the object on the floor to see if it is brittle or not (not all non-metals are brittle though), they could see whether the surface is dull (non-metal) or shiny (metal), they could see whether the object is strong and hard (metal) or soft and bendy (non-metal). But it is important to point out that you cannot just do one of these tests to make a conclusion as there will be some exceptions, such as plastic is hard and smooth like a metal, but it is brittle. So learners need to do more than one test to make a conclusion. This is explored further in the next question.

Sometimes, just using one property to classify an object or material as a metal or non-metal might not be enough. For example, plastic is flexible but strong, so does this make it a metal? The answer is no. Another example is glass. Glass is also hard, but is it strong? What other properties does glass have which make it a non-metal and not a metal?







Glass is not strong, as it is brittle and can crack and break easily. It does not have the lustre of metal, and it can't be hammered into flat sheets or made into thin wires (it is not malleable or ductile).
